JUYI 500V/8A N Channel Enhancement Mode Power MOSFET with Fast switching and reverse body recovery

Absolute Maximum Ratings(Tc=25ºC Unless Otherwise Noted)

Symbol	Parameter		Limit	Unit
VDS	Drain-Source Voltage		500	V
VGS	Gate-Source Voltage		±30	V
ID	Continuous Drain Current	Tc=25ºC	8	A
		Tc=100ºC	4.8
IDM	Pulsed Drain Current		30	A
PD	Maximum Power Dissipation		80	W
TJ TSTG	Operating Junction and Storage Temperature Range		-55+150	ºC
RθJC	Thermal Resistance-Junction to Case		1.56	℃/W

Electrical Characteristics(Tc=25ºC Unless Otherwise Noted)

Electrical Characteristics(Ta=25ºC Unless Otherwise Noted)
